New 2025 Chevrolet 4500 HG LCF Gas Base RWD 2D Standard Cab

VIN: 54DCDW1D0SS203155
Stock: 150492

(10) Photos

MSRP $73,335

Final Selling Price $71,585

Basic Info

Exterior:

White
Drivetrain:

RWD
Interior:

Gray
Transmission:

8-Speed Automatic
Engine:

6.6L V8

Key Features

Backup Camera
Bluetooth
Keyless Entry

Description

Arc White 2025 Chevrolet 4500 HG LCF Gas RWD 8-Speed Automatic 6.6L V8

Our dealer has a tenured professionally managed Service and Parts department open extended hours to accommodate our customer’s busy schedules: and as always we offer competitive pricing for your automotive maintenance needs. Proudly servicing, Auburn, Kent Puyallup, Seattle, Lakewood, Everett, Snohomish, Bellevue, Kirkland, Tacoma and Bellingham. Price includes: $1750 - GM Envolve Consumer Cash Program. Exp. 09/30/2026 Price includes $200 dealer added accessories.

Vehicle Details

Tires, front, 225/70R19.5 G, LRR (low rolling resistance) tubeless steel belted radial, all-season
Tires, rear, 225/70R19.5 G, LRR (low rolling resistance) tubeless steel belted radial, all-season
Assist steps
LED Headlamps
Grille, Silver
Glass, tinted
Mirror, outside left-hand and right-hand with integral convex mirrors
Windshield wiper, pulse, wet arm

Cup holders
Floor mats
Steering wheel, urethane
Steering column, Tilt-Wheel
Driver Information Center
Windows, power
Air conditioning, single-zone manual, integral in-dash mounted
Windshield washer bottle access on passenger side dash when passenger-side door is open
Storage, door pockets
Lighting, interior dome
Storage, seatback pockets

Audio system feature, 2 speakers

Engine, 6.6L V8 SIDI, GMPT-V8 8 cylinder V Iron block, four cycle overhead valve water cooled 6.6L SIDI V8 350 hp [261 kW] @ 4500 rpm, 425 lb.-ft of torque [575.8 N-m] @ 3800 rpm. Electronically controlled direct fuel injection. Six bolt main cap design for heavy-duty performance. Engine Control Module (ECM) and Transmission Control Module (TCM) engine control system. Engine cruise control, engine oil cooler, High Idle Mode (1200 rpm).
Rear axle, 4.10 ratio
Drivetrain, rear-wheel drive
Battery, 750 cold-cranking amps, 12-volt single, maintenance free, frame-mounted battery box
Frame, ladder-type channel frame. Full C section straight frame 33.5" (85.1 cm) wide. Yield strength 44,000 psi, section modulus 7.20 cu.in. and RBM 316,800 lb-ft/in per rail.
Incomplete vehicle certification
Wheelbase, 176" (447.0 cm)
GVWR, 14,500 lbs. (6577 kg)
Rear suspension, 12,900 lbs. (5851 kg), multi-leaf, semi-elliptical steel alloy. Includes shock absorbers
Front axle, 6,830 lbs. (3098 kg), reverse Elliot "I"-beam includes integral hydraulic power steering, with an 18.8-20.9:1 gear ratio
Brakes, 4-wheel antilock, front and rear disc
Vehicle Application Truck
Fuel tank, 38.6 Gallon, (146L), rectangular fuel tank mounted between frame rail with electric type fuel pump (mounted in tank). Through the rail fuel fill.
Exhaust, single outlet

Brake, parking, cable actuated, internal expanding drum type, transmission-mounted
Daytime Running Lamps

Vehicle Name: Chevrolet 4500 HG LCF Gas
Body Style: Regular Cab Chassis Cab
Body Code:
Drivetrain: Rear Wheel Drive
Passenger Capacity: 3
Number of Passenger Doors: 2
Gross Axle Wt Rating - Front: 6630
Gross Axle Wt Rating - Rear: 11020
Curb Weight - Front: 3753
Curb Weight - Rear: 2230
Gross Vehicle Weight Rating Cap: 14500
Gross Combined Wt Rating: 20500
Engine Order Code: L8T
Engine Type: Gas V8
Displacement: 6.6L/- TBD -
Fuel System: Direct Fuel Injection
SAE Net Horsepower @ RPM: 350 @ 4500
SAE Net Torque @ RPM: 425 @ 3800
Trans Order Code: N8X
Trans Type: 8
Trans Description Cont.: Automatic
Trans Description Cont. Again:
First Gear Ratio (:1): - TBD -
Second Gear Ratio (:1): - TBD -
Third Gear Ratio (:1): - TBD -
Fourth Gear Ratio (:1): - TBD -
Fifth Gear Ratio (:1): - TBD -
Sixth Gear Ratio (:1): - TBD -
Reverse Ratio (:1): - TBD -
Clutch Size:
Trans Power Take Off:
Trans PTO Access:
Transfer Case Model:
Transfer Case Gear Ratio (:1), High:
Transfer Case Gear Ratio (:1), Low:
Transfer Case Power Take Off:
Cold Cranking Amps @ 0° F (Primary): 750
Cold Cranking Amps @ 0° F (2nd):
Cold Cranking Amps @ 0° F (3rd):
Maximum Alternator Capacity (amps): 170
Maximum Alternator Watts: - TBD -
Total Cooling System Capacity: - TBD -
Engine Oil Cooler: Yes
Frame Type: Ladder-Type Channel-Section
Sect Modulus Rails Only: 7.20
Frame RBM: 316800
Frame Strength: 44000
Frame Thickness: 8.50 X 2.76 X 0.24
Suspension Type - Front: Semi-Elliptical Multi-Leaf Spring
Suspension Type - Rear: Semi-Elliptical Multi-Leaf Spring
Spring Capacity - Front: 6830
Spring Capacity - Rear: 12900
Axle Type - Front: Reverse Elliot I-Beam
Axle Type - Rear: Full-Floating
Axle Capacity - Front: 6830
Axle Capacity - Rear: 11020
Axle Ratio (:1) - Front:
Axle Ratio (:1) - Rear: 4.10
Shock Absorber Diameter - Front: 42.0
Shock Absorber Diameter - Rear: 42.0
Stabilizer Bar Diameter - Front: 1.65
Stabilizer Bar Diameter - Rear:
Front Tire Order Code: 2TC
Rear Tire Order Code: 3TC
Spare Tire Order Code:
Front Tire Size: 225/70R19.5
Rear Tire Size: 225/70R19.5
Spare Tire Size:
Front Tire Capacity: 6630
Rear Tire Capacity: 12460
Spare Tire Capacity:
Revolutions/Mile @ 45 mph - Front: 643
Revolutions/Mile @ 45 mph - Rear: 643
Revolutions/Mile @ 45 mph - Spare:
Front Wheel Size: 19.5 x 6.0
Rear Wheel Size: 19.5 x 6.0
Spare Wheel Size:
Front Wheel Offset: 127
Rear Wheel Offset: 127
Spare Wheel Offset:
# of Bolt Holes - Front: 6
# of Bolt Holes - Rear: 6
# of Bolt Holes - Spare:
Front Wheel Material: Steel
Rear Wheel Material: Steel
Spare Wheel Material:
Steering Type: Pwr
Steering Ratio (:1), On Center: 18.8 - 20.9
Steering Ratio (:1), At Lock: 18.8 - 20.9
Turning Diameter - Curb to Curb: 51.9
Turning Diameter - Wall to Wall: 58.0
Brake Type: Pwr
Brake ABS System: 4-Wheel
Brake ABS System (Second Line):
Disc - Front (Yes or ): Yes
Disc - Rear (Yes or ): Yes
Front Brake Rotor Diam x Thickness: 11.5 x - TBD -
Rear Brake Rotor Diam x Thickness: - TBD -
Drum - Front (Yes or ):
Front Drum Diam x Width:
Drum - Rear (Yes or ):
Rear Drum Diam x Width:
Fuel Tank Capacity, Approx: 38.6
Aux Fuel Tank Capacity, Approx:
Fuel Tank Location: Frame Rail
Aux Fuel Tank Location:
Front Head Room: 38.40
Front Leg Room: 29.50
Front Shoulder Room: 70.70
Front Hip Room: 67.70
Wheelbase: 176
Length, Overall: 267.5
Width, Max w/o mirrors: 81.3
Height, Overall: 90.9
Overhang, Front: 48.4
Overhang, Rear w/o bumper: 43.1
Front Bumper to Back of Cab: 70.9
Cab to Axle: 153.5
Cab to End of Frame: 196.6
Ground to Top of Load Floor:
Ground to Top of Frame: 33.0
Frame Width, Rear: 33.5
Ground Clearance, Front: 8.3
Ground Clearance, Rear: 8.3
Front Frame Rating: - TBD -
Seventh Gear Ratio (:1): - TBD -
Eighth Gear Ratio (:1): - TBD -
Ninth Gear Ratio (:1):
Tenth Gear Ratio (:1):
Eleventh Gear Ratio (:1):
Twelfth Gear Ratio (:1):
Thirteenth Gear Ratio (:1):
Fourteenth Gear Ratio (:1):
Fifteenth Gear Ratio (:1):
Sixteenth Gear Ratio (:1):
Seventeenth Gear Ratio (:1):
Eighteenth Gear Ratio (:1):
Nineteenth Gear Ratio (:1):
Twentieth Gear Ratio (:1):
Second Reverse Gear Ratio (:1):
Third Reverse Gear Ratio (:1):
Fourth Reverse Gear Ratio (:1):
Fifth Reverse Gear Ratio (:1):
Sixth Reverse Gear Ratio (:1):
Body Weight (uncalculated): - TBD -
Driver Weight: - TBD -
Axle Ratio - Low Rear (:1):
Driver Ratio: - TBD -
Torque @ Clutch Engage: - TBD -
Cab to Body: - TBD -
Grade (%): - TBD -
Frontal Area: - TBD -
Governed Engine Speed (RPM):
Torque Converter:
Front Wheel Description Cont.:
Rear Wheel Description Cont.:
Spare Wheel Description Cont.:
Static Loaded Radius: - TBD -
Front Bolt Pattern: 6 Hole JIS 8.75"
Rear Bolt Pattern: 6 Hole JIS 8.75"
Spare Bolt Pattern:
Number Of Tires Front: 2
Number Of Tires Rear: 4
Number Of Tires Spare:
Transmission Manufacturer:
Transmission Type:
Engine Series: GMPT
Body Length Default Value: - TBD -
Engine Horsepower At RPM: 350 @ 4500
Engine Horsepower At Max Speed RPM: - TBD -
Max Speed For Gradeability: - TBD -
Model Group: 4500
Vehicle Segment: Chassis
Vehicle Type: Standard Cab
Engine Displacement Units: 6.6
Engine Camshaft: OHV
Engine Block Type: iron
Engine Cylinder Count: 8
Engine Valve Count: 2
Country of Origin: United States N-Gas, F-Series and N-EV Incomplete vehicles

Preferred Equipment Group 1WT
Seat-Cover Protector
High Back Front Bucket Seats
Remote Keyless Entry
Single-Zone Manual Air Conditioning
Roof-Air Deflector
Chrome Grille
AM/FM Stereo with Seek and Scan and Digital Clock
Fire Extinguisher and Safety Triangle
38.6 Gallon/146 L Rectangular Fuel Tank
19.5" x 6" Steel Wheels
Tricot Cloth Seat Trim
750 CCA 12V Maintenance Free Single Battery
2 Speakers Audio System Feature
AM/FM Stereo with CD Player and Bluetooth
Rear Vision Camera
Back-Up Alarm
Extra Set of Keys
4-Wheel Disc Brakes
Dual rear wheels
2 Speakers
Trip computer
Tilt steering wheel
Telescoping steering wheel
Speed control
Power windows
Power steering
Passenger door bin
Overhead console
Front anti-roll bar
Driver door bin
CD player
Bumpers: body-color
AM/FM radio
ABS brakes
Tachometer
Front Center Armrest
Front Bucket Seats
Air Conditioning
A/C
ABS
Rear Wheel Drive
8 Cylinder Engine
Floor Mats
Gasoline Fuel
Daytime Running Lights
Power Door Locks
Running Boards/Side Steps
Cloth Seats
Bucket Seats
Power Steering
Adjustable Steering Wheel
Tires - Front All-Season
Tires - Rear All-Season
Power Windows
A/T
Steel Wheels
Bluetooth Connection
8-Speed A/T
LED Headlights

Premium Options & Packages

                            Rear Vision Camera

                            AM/FM Stereo with CD Player and Bluetooth

                            Remote Keyless Entry
ENGINE, 6.6L V8 SIDI, GMPT-V8 8 CYLINDER V IRON BLOCK, FOUR CYCLE OVERHEAD

                                                                    Valve water cooled 6.6L SIDI V8 350 hp [261 kW] @ 4500 rpm
 425 lb.-ft of torque [575.8 N-m] @ 3800 rpm. Electronically controlled direct fuel injection. Six bolt main cap design for heavy-duty performance. Engine Control Module (ECM) and Transmission Control Module (TCM) engine control system. Engine cruise control
 engine oil cooler
 High Idle Mode (1200 rpm).

PAINT

                                                                    ARC WHITE

RADIO

                                                                    AUDIO SYSTEM
 AM/FM STEREO WITH CD PLAYER
 AUXILIARY JACK
 USB PORT AND BLUETOOTH

SEAT, FRONT HIGH BACK BUCKET DRIVER AND PASSENGER

                                                                    Tricot cloth covered reclining high back driver seat with single two-occupant fold down passenger seat

TRANSMISSION

                                                                    TRANSMISSION
 8-SPEED AUTOMATIC
 8L90

WHEELS

                                                                    WHEELS
 19.5" X 6"
 K STEEL
